LABOPORT N938.50KT.18 mini-membrane vacuum pump, 1.8 m³/h, 15 mbar, PTFE images
LABOPORT N938.50KT.18 mini-membrane vacuum pump, 1.8 m³/h, 15 mbar, PTFE
Price:
zł6,897.38
VAT excluded
LABOPORT N938.50KT.18 mini-membrane vacuum pump, 1.8 m³/h, 15 mbar, PTFE
- Mini-membrane vacuum pump N 938.50 KT.18 - Flow rate 1.8 m³/h / ultimate vacuum 15 mbar abs. - Parallel and series connection of the two pump heads ensures very fast evacuation - PTFE-coated diaphragm for aggressive/corrosive gases and vapours Technical data Application Filtration, SPE, degassing Flow rate (m³/h) at atm. pressure 1.8 Ultimate vacuum (mbar abs.) 15 Operating overpressure (bar) 0.5 Hose connections (mm) ID10 Permissible media and ambient temperature +5 ... +40 °C Weight (kg) 6.8 Dimensions W x H x D (mm) 110 x 212 x 317 Pump head material PPS Diaphragm PTFE-coated Valves FFPM Accessories Silencer Order No. 007006 Hose nipple G1/8 ID10 PVDF Order No. 112004 Fine adjustment valve with vacuum meter, on the suction side, for adjusting the vacuum Order No. 112432 Accessories (optional): Vacuum chemical hose 028187 Silencer 056366 (mounted using a hose on the outlet side)
-
Brand
-
Reference9983667
Secure B2B procurement
Encrypted data transmission and personal order review.
Delivery after confirmation
Lead time and availability are confirmed during the order or inquiry process.
Returns by prior agreement
B2B returns require prior agreement and follow the applicable contract terms.
