SIMDOS 02 FEM1.02TT.18RCP PVDF diaphragm dosing pump

Chemical-resistant diaphragm dosing pump SIMDOS® 02 TT.18 RC P - flow rate of 0.03 - 20 ml/min / pressure head 60 mWC, suction head 2 mWC - pump head made of PVDF - diaphragm made of PTFE, valves made of FFKM - flow rate can be adjusted manually and via external control, including RS 232 interface (RC Plus version) - additional safety diaphragm for maximum protection - easy replacement of the dosing diaphragm by activating the maintenance command stored in the operating program Technical data Application Dosing liquids Flow rate (ml/min) with water at 20 °C at zero head 0.03 - 20 Pressure head (mWC) 60 Suction head (mWC) 2 Hose connection (mm) ID1.6 / AD3.2 Permissible media and ambient temperature Ambient temperature +5 ... +40 °C Media temperature +5 ... +80 °C Weight (kg) 0.9 Dimensions W x H x D (mm) 93 x 144 x150 Pump head material PVDF Diaphragm PTFE Valves FFKM Included in delivery: -Dosing pump -Suction filter -2 metres of connection tubing -Power supply Accessories (not included in delivery): Stand holder Order no. 160474 Wall holder Order no. 160473 Foot switch for RCP version (RCP = manual operation and external control) Order no. 155872 In-line filter FS 60 T PVDF mesh size 70 µm Order no. 165210 FS 60 X PEEK mesh size 35 µm Order no. 165212 Back-pressure valve JFDV30FTZ: 166288 (PTFE) Back-pressure valve JFDV30TTZ: 166287 (PVDF) Back-pressure valve JFDV30KTZ: 166286 (PP)
