Refrigerated thermostat LAUDA Universa U 630 P, -30 ... 200 °C, 5,7 L

LAUDA Universa U 630 P refrigerated thermostat, 200-240 V; 50/60 Hz Performance features: Bath circulator thermostat with advanced electronics ensures precise control accuracy Future-proof through modularity: LAUDA Universa with interchangeable control head and heating/cooling lower section enables flexible adaptation to current and future requirements Clear overview, intuitive operation: The colour 3,5-inch TFT display with trend graphics offers clear menu navigation in six languages and clear operating status symbols, easily controlled via cursor and soft keys. Safety in focus: The dedicated Tmax button provides convenient access to the essential overtemperature protection setting during commissioning. Efficient Variopump with six adjustable performance levels. Flexible flow distribution for internal and external circulation ensures optimum volume flow and pressure. Easily accessible front switch on the control head enables adjustment of pump performance during operation. Energy-efficient refrigeration system: Capillary tube technology with speed-controlled inverter compressor and speed-controlled fan for reduced energy costs and long service life. Environmentally friendly refrigerants: Use of natural refrigerants for sustainable and environmentally conscious cooling. Adaptive bath rim ventilation (patent pending): - Prevents icing and condensation - Stops water entering the bath - Blocks vapours to protect the electronics. To increase operational safety and extend service life. The range of functions includes a programmer, calibration options and weekly scheduler for versatile and precise process control. Intelligent remote control and monitoring: Integrated web server enables flexible remote operation in the company network via the LAUDA Command App or browser, secured by PKI and 2-factor authentication. Connection to LAUDA.LIVE enables worldwide, cloud-based data analysis and remote maintenance. Flexible networking: Modern connectivity through standard-integrated Ethernet and USB interfaces as well as ten optional interface modules for versatile communication solutions. Wireless communication: Integrated WLAN enables effortless connection with PC, tablet and smartphone. Comprehensive safety concept: - Reliable low-level protection with float technology, - Adjustable overtemperature protection with acoustic alarm, - Smart temperature-control medium management with automatic limit-value adjustment. For reliable operation and improved safety of your valuable samples. Technical data: Operating temperature range: -30 ... 200 °C Operating temperature range: -30 ... 200 °C Ambient temperature range: 5 ... 40 °C Temperature constancy: 0,02 ± K Heating power range: 2.3 ... 2.8 kW Current consumption: 12 A Bath size (WxDxH): 130 x 150 x 160 mm Bath opening (WxD): 130 x 150 mm Bath volume min. / max.: 3,2 / 5,7 L Pump pressure max.: 0,6 bar Pump flow rate max. (pressure): 22 L/min In / Outlet connection thread (external): M16 x 1 Dimensions (WxDxH): 215 x 460 x 616 mm Weight: 28 kg Refrigerant stage 1: R-600a (GWP 3); 0,030 kg; 0,0 t CO2-eq Power supply: 220-240 V; 50/60 Hz Power plug: Power cable with angled Schuko plug (CEE7/7) Cooling capacity (pump stage): 200 °C (6); thermal oil 100 °C (6); thermal oil 20 °C (6); ethanol; 0,3 kW (50 Hz); 0,3 kW (60 Hz) 10 °C (6); ethanol; 0,29 kW (50 Hz); 0,29 kW (60 Hz) 0 °C (6); ethanol; 0,25 kW (50 Hz); 0,25 kW (60 Hz) -10 °C (6); ethanol; 0,19 kW (50 Hz); 0,19 kW (60 Hz) -20 °C (3); ethanol; 0,12 kW (50 Hz); 0,12 kW (60 Hz) -30 °C (3); ethanol; 0,02 kW (50 Hz); 0,02 kW (60 Hz) Standard accessories: 1 bath cover Pump connection set with M16x1 stainless steel connections 2 union nuts, 2 sealing plugs
