LABOPORTN 820.3 FT.18 PTFE diaphragm pump | Hornik

LABOPORTN 820.3 FT.18 PTFE diaphragm vacuum pump, 1.2 m³/h, 8 mbar, ATEX, for aggressive gases

€2,015.83
VAT excluded
LABOPORTN 820.3 FT.18 PTFE diaphragm vacuum pump, 1.2 m³/h, 8 mbar, ATEX, for aggressive gases

Product images may differ from the original.

Technical consulting for your application

Need support with selection or specification? Send us an inquiry.

Suitable for projects, framework agreements and institutional procurement

Delivery time, availability and project details are confirmed during inquiry or ordering.

Send inquiry
Personal support +49 2261 815870 Mon–Thu 08:00–16:00, Fri 08:00–13:00

Diaphragm vacuum pump N 820.3 FT.18 - flow rate 1.2 m³/h / ultimate vacuum 8 mbar abs. - High resistance to vapour and condensate - PTFE pump head combined with a PTFE-coated diaphragm is ideal for very aggressive/corrosive gases and vapours - ATEX-compliant according to ATEX II 2G IIB+H2 T3X internal atmosphere only - Also available with integrated gas ballast: N 820.3 FT.18 G Technical data Application Degassing, gel drying, rotary evaporation Flow rate (m³/h) at atm. pressure 1.2 Ultimate vacuum (mbar abs.) 8 Operating overpressure (bar) 1 Hose connections (mm) ID10 Permissible media and ambient temperature +5 ... +40 °C Weight (kg) 9.3 Dimensions W x H x D (mm) 154 x 207 x 312 Pump head material PTFE Diaphragm PTFE-coated Valves FFPM Accessories (optional): Silencer: 007007 (installation on the pump head) Silencer: 056366 (installation on the outlet side using a hose) Vacuum chemical hose ID 9.4 mm (supplied in whole metres): 028187

  • Reference
    9983705
